Setting up OpenLDAP on Rocky Linux 9

02/09/2025

0 Views 0

SaveSavedRemoved 0

A Step-by-Step Guide to Installing and Configuring OpenLDAP on Rocky Linux 9

Centralized authentication is a cornerstone of modern IT infrastructure, allowing for streamlined user management and enhanced security across multiple systems. OpenLDAP, the premier open-source implementation of the Lightweight Directory Access Protocol, provides a robust and flexible solution for creating a central directory service. This guide will walk you through the complete process of installing and configuring an OpenLDAP server on Rocky Linux 9, from initial setup to client authentication.

Prerequisites

Before you begin, ensure you have the following:

A running instance of Rocky Linux 9.
Root or sudo privileges.
A basic understanding of the Linux command line.

Step 1: Installing the Necessary OpenLDAP Packages

The first step is to install the OpenLDAP server and client packages from the default Rocky Linux repositories. The server package contains the core daemon (slapd), while the client package provides command-line utilities for interacting with the directory.

Open your terminal and execute the following command:

sudo dnf install openldap-servers openldap-clients

This command will download and install all the required dependencies for running your LDAP server.

Step 2: Initializing the OpenLDAP Configuration

Once installed, you need to prepare the database environment. OpenLDAP comes with a sample database configuration file that serves as an excellent starting point.

Copy the sample configuration file to the OpenLDAP data directory:

sudo cp /usr/share/openldap-servers/DB_CONFIG.example /var/lib/ldap/DB_CONFIG

Assign the correct ownership to the data directory. The OpenLDAP service runs as the ldap user, so it needs permission to manage these files:
```
sudo chown -R ldap:ldap /var/lib/ldap
```

Step 3: Starting and Enabling the SLAPD Service

With the initial configuration in place, you can start the OpenLDAP server daemon, known as slapd.

Start the service:
```
sudo systemctl start slapd
```
Enable the service to start automatically on boot:
```
sudo systemctl enable slapd
```
Verify that the service is running without any errors:
```
sudo systemctl status slapd
```

You should see an “active (running)” status in the output.

Step 4: Configuring Firewall Rules for LDAP

For clients to connect to your OpenLDAP server, you must allow traffic through the system’s firewall. LDAP uses port 389 for standard connections and port 636 for secure connections (LDAPS).

Execute the following commands to permanently add a rule for the standard LDAP service and reload the firewall:

sudo firewall-cmd --add-service=ldap --permanent
sudo firewall-cmd --reload

Step 5: Securing the Root DSE and Defining Your Directory Structure

Now it’s time to configure the core components of your directory: the administrator password and the directory’s base structure.

Generate a Hashed Administrator Password
Never store the root password in plaintext. Use the slappasswd utility to generate a secure, hashed password.
```
slappasswd
```
Enter your desired password twice. The command will output a hash string, such as {SSHA}abcdef123.... Copy this entire string, as you will need it shortly.
Create an LDIF File for the Root Password
Create a file named root_password.ldif and add the following content. Replace {SSHA}your_hashed_password with the hash you just generated.
```
dn: olcDatabase={2}mdb,cn=config
changetype: modify
replace: olcRootPW
olcRootPW: {SSHA}your_hashed_password
```
Apply the Password Change
Use the ldapmodify command to apply this change. The -Y EXTERNAL and -H ldapi:/// options allow you to authenticate securely over a local Unix socket without needing a password.
```
sudo ldapmodify -Y EXTERNAL -H ldapi:/// -f root_password.ldif
```

Import Core Schemas
To store common object types like users and groups, you must import standard schemas.

sudo ldapadd -Y EXTERNAL -H ldapi:/// -f /etc/openldap/schema/cosine.ldif
sudo ldapadd -Y EXTERNAL -H ldapi:/// -f /etc/openldap/schema/nis.ldif
sudo ldapadd -Y EXTERNAL -H ldapi:/// -f /etc/openldap/schema/inetorgperson.ldif

Define Your Base Distinguished Name (DN)
Your Base DN is the root of your directory tree. This is typically based on your domain name. For example, if your domain is example.com, your Base DN would be dc=example,dc=com.
Create a file named base_dn.ldif with the following content, replacing example and com with your own domain details.
```
dn: olcDatabase={2}mdb,cn=config
changetype: modify
replace: olcSuffix
olcSuffix: dc=example,dc=com

dn: olcDatabase={2}mdb,cn=config
changetype: modify
replace: olcRootDN
olcRootDN: cn=Manager,dc=example,dc=com
```
Apply this configuration file:
```
sudo ldapmodify -Y EXTERNAL -H ldapi:/// -f base_dn.ldif
```

Step 6: Adding Organizational Units, Groups, and Users

With the directory structure defined, you can now populate it. A common practice is to create Organizational Units (OUs) to hold your users and groups.

Create an LDIF file for your base structure named structure.ldif. This example creates OUs for “People” (users) and “Group”.

dn: dc=example,dc=com
objectClass: top
objectClass: dcObject
objectclass: organization
o: Example Corp
dc: example

dn: cn=Manager,dc=example,dc=com
objectClass: organizationalRole
cn: Manager
description: Directory Manager

dn: ou=People,dc=example,dc=com
objectClass: organizationalUnit
ou: People

dn: ou=Group,dc=example,dc=com
objectClass: organizationalUnit
ou: Group

Add the structure to your directory. This time, you will authenticate using the Manager DN and the password you set earlier.
```
ldapadd -x -D "cn=Manager,dc=example,dc=com" -W -f structure.ldif
```
The -W flag will prompt you for the LDAP root password.

Step 7: Configuring a Rocky Linux Client for LDAP Authentication

The final step is to configure a client machine to use your new OpenLDAP server for user authentication.

On the client machine, install the necessary packages:
```
sudo dnf install openldap-clients sssd-ldap
```
Use authselect to configure the system for authentication via SSSD (System Security Services Daemon). This command also enables the automatic creation of home directories for network users upon their first login.
```
sudo authselect select sssd with-mkhomedir
```

Configure SSSD by editing the /etc/sssd/sssd.conf file. Add the following configuration, replacing the ldap_uri and ldap_search_base with your server’s IP/hostname and Base DN.

[sssd]
services = nss, pam
domains = default

[nss]
filter_groups = root
filter_users = root

[pam]

[domain/default]
id_provider = ldap
auth_provider = ldap
ldap_uri = ldap://your_ldap_server_ip
ldap_search_base = dc=example,dc=com
ldap_id_use_start_tls = True
cache_credentials = True
ldap_tls_reqcert = allow

Secure the configuration file as it may contain sensitive information.
```
sudo chmod 600 /etc/sssd/sssd.conf
```

Restart and enable the SSSD service:

sudo systemctl restart sssd
sudo systemctl enable sssd

To test, you can now try to SSH into the client machine using an LDAP user’s credentials or use the id <ldap_username> command to verify that the client can retrieve user information from the LDAP server.

Essential Security Best Practices for OpenLDAP

Implement TLS/SSL (LDAPS): The configuration above uses start_tls, which is good, but for maximum security, configure your server to use LDAPS on port 636. This encrypts all communication between clients and the server, protecting credentials and data in transit.
Use Strong Access Control Lists (ACLs): The default OpenLDAP ACLs are a good starting point, but they should be reviewed and tightened. Restrict read/write access based on the principle of least privilege to prevent unauthorized data exposure or modification.
Regularly Audit and Monitor Logs: Keep a close eye on OpenLDAP logs for suspicious activity, such as a high number of failed bind attempts, which could indicate a brute-force attack.
Keep Software Updated: Regularly update your OpenLDAP packages using dnf to protect against known vulnerabilities.

Source: https://kifarunix.com/install-and-setup-openldap-on-rocky-linux-9/
