A Step-by-Step Guide to SSSD and OpenLDAP Authentication on CentOS 8
Managing user accounts across multiple servers can quickly become a complex and error-prone task. A centralized authentication system is the solution, providing a single source of truth for user credentials and permissions. For Linux environments, combining OpenLDAP with the System Security Services Daemon (SSSD) on a platform like CentOS 8 creates a robust, secure, and efficient authentication framework.
SSSD is a modern daemon that offers significant advantages over older methods. It provides a stable and feature-rich interface for connecting a system to remote identity and authentication providers. Key benefits include offline authentication caching, reduced load on your LDAP server, and a more streamlined configuration process.
This guide will walk you through the essential steps to configure a CentOS 8 client to authenticate against an OpenLDAP server using SSSD.
Prerequisites
Before you begin, ensure you have the following:
- A fully operational CentOS 8 server.
- Root or sudo-level privileges on the server.
- A running OpenLDAP server with users and groups already configured.
- The connection details for your OpenLDAP server, including the server URI and the search base Distinguished Name (DN).
Step 1: Install Necessary SSSD and LDAP Packages
The first step is to install the required software packages. The SSSD suite, along with OpenLDAP client utilities, contains everything needed to connect to your directory server.
Open your terminal and execute the following command:
sudo dnf install sssd sssd-tools openldap-clients -y
This command installs:
sssd: The core SSSD daemon and its common modules.sssd-tools: A collection of helpful command-line tools for managing and troubleshooting SSSD.openldap-clients: Utilities for querying the OpenLDAP server, which are invaluable for testing.
Step 2: Configure the SSSD Client
With the packages installed, the next critical step is creating the SSSD configuration file. This file, located at /etc/sssd/sssd.conf, tells the SSSD daemon how to connect and interact with your OpenLDAP server.
Create and open the file with your preferred text editor:
sudo vi /etc/sssd/sssd.conf
Paste the following configuration template into the file, and then customize the values to match your specific environment.
[sssd]
services = nss, pam
config_file_version = 2
domains = default
[nss]
filter_groups = root
filter_users = root
[pam]
[domain/default]
id_provider = ldap
auth_provider = ldap
chpass_provider = ldap
# LDAP Server Connection Details
ldap_uri = ldap://ldap.yourdomain.com
ldap_search_base = dc=yourdomain,dc=com
# Use this for encrypted connections (recommended)
# ldap_tls_reqcert = allow
# ldap_tls_cacert = /etc/openldap/certs/ca.pem
# Enables creating home directories for LDAP users on their first login
create_homedir = true
default_shell = /bin/bash
homedir_template = /home/%u
# Improves performance by caching entries
cache_credentials = True
Key Configuration Parameters Explained:
[sssd]section: Defines the core services SSSD will provide (nssfor name lookups andpamfor authentication) and lists the authentication domains.domains = default: Establishes a domain named “default” which is defined in the[domain/default]section.[domain/default]section: This is where you configure the connection to your identity provider.id_provider = ldap: Specifies that user identity information (like usernames, UIDs, and group memberships) comes from an LDAP server.auth_provider = ldap: Specifies that user password verification will be handled by the same LDAP server.ldap_uri: This is the address of your OpenLDAP server. Replaceldap://ldap.yourdomain.comwith your server’s URI. For secure connections, useldaps://and configure the TLS settings.ldap_search_base: This is the base DN of your LDAP directory. It tells SSSD where to start searching for users and groups. Replacedc=yourdomain,dc=comaccordingly.create_homedir = true: A highly useful feature that automatically creates a user’s home directory upon their first successful login.
Security Tip: The sssd.conf file can contain sensitive information. Once you have saved your configuration, it is crucial to set the correct permissions to prevent unauthorized access.
sudo chmod 600 /etc/sssd/sssd.conf
Step 3: Enable SSSD for System-Wide Authentication
After configuring SSSD, you need to tell the system to use it for authentication. On CentOS 8, the authselect command is the modern and preferred way to manage the system’s authentication profile.
Run the following command to select the SSSD profile and enable the automatic creation of home directories:
sudo authselect select sssd with-mkhomedir
This command modifies the necessary PAM (/etc/pam.d/) and NSS (/etc/nsswitch.conf) files, integrating SSSD deeply into the system’s login and user lookup processes.
Step 4: Start and Enable the SSSD Service
Now it’s time to bring the SSSD daemon online. You need to both start the service for the current session and enable it to launch automatically on system boot.
sudo systemctl start sssd
sudo systemctl enable sssd
To check the status of the service and ensure it started without errors, you can run:
sudo systemctl status sssd
Step 5: Verify the LDAP Integration
The final step is to verify that your system can successfully see and retrieve user information from the OpenLDAP server.
Use the id command to check for a user that exists in your LDAP directory but not locally on the machine.
id ldapuser
If the configuration is correct, you will see the user’s UID, GID, and group memberships returned from the LDAP server. A “no such user” message indicates a problem with your sssd.conf file or a connectivity issue.
You can also use the getent command for a more thorough check:
getent passwd ldapuser
This should return the user’s entry in a format similar to the local /etc/passwd file.
Common Troubleshooting Steps
If you encounter issues, here are a few things to check:
- Check SSSD Logs: The logs are your best friend. The main log file is
/var/log/sssd/sssd.log, with specific logs for each domain (e.g.,/var/log/sssd/sssd_default.log). - Firewall Rules: Ensure that the firewall on your CentOS 8 client and the LDAP server allows traffic on the necessary ports (typically port 389 for LDAP and port 636 for LDAPS).
- SELinux: SELinux can sometimes block SSSD’s operations. Check the audit log with
ausearch -m avc -ts recentto see if there are any denials related tosssd. If needed, you might have to adjust SELinux booleans. - Configuration Syntax: A small typo in
/etc/sssd/sssd.confcan prevent the service from starting. Double-check yourldap_uriandldap_search_basevalues.
By successfully integrating SSSD with OpenLDAP, you have built a powerful, centralized authentication system that enhances security, simplifies user management, and provides a seamless login experience for your users.
